Features
Number of rungs / steps: 12
Medium designation (80)
Pronor flared combination 3 sections 3x12 rung aluminium
Reference
01253012
Barcode
3178740187293
Brand
Tubesca
Label
NF 93
Standards
EN 131
Decree
96-333
Guarantee
5 year
Class
Professional
Number of rungs / steps
12
Maximum access height
8,49 m
Main material
Aluminium
Overall width (without stab)
1,18 m
Overall width (with stab - max adjustment)
1,18 m
Thickness of folded product
0,23 m
Upright section
79/90/79
Weight
25,20 kg
Maximum load
150 kg
Type of floor
Flat surface, Uneven surface
Colour Label
Light grey - RAL 7035
Made in france
Made in France
Percentage of recyclable material in the product
92
Percentage of recyclable material in the packaging
10
Carbon impact kg eq. CO2
166.746
Details
The Pronor aluminium three-section combination ladder features cast aluminium joints, a flared base and a steel spreader arm guaranteeing reliability and comfort for all users.- Lightweight and easy to handle for simple installation and transport.
- 30 x 30 mm rungs for comfort of use.
- Extreme rigidity with a ribbed joint reinforced with cast aluminium and a rigid anti-spreading arm.
- Versatile for use on flat surface and stairways.
- The most versatile model in the Pronor range
- Non-detachable third section for the 3 x 12 rung model
30 x 30mm rungs
Ultra-strong rungs through double expansion crimping
Ultra-strong rungs through double expansion crimping
Level offset possible
Interlocking hooks
2 hooks on the upper section are placed on the rungs of the lower section
Flared base for added stability
Download the documentation
Accessories and complementary products
Spare parts
Exploded view – PDFName of spare part
Pronor flared combination 3 sections 3x12 rung aluminium
